Phoenix Gold ZX8C ZXC-series 8 inch 209mm PRO Midrange Speakers/Subwoofers Pair RMS 120W -250W MAX
The Phoenix Gold ZX84C is a 8″ midbass/midrange subwoofers.
Unleash powerful midbass performance with the ZX8C. Engineered for precision and punch, this 8” (209mm) driver is designed to deliver tight, impactful midbass that brings your music to life.
Built with a 1.5” copper voice coil and capable of handling 120W RMS / 240W MAX, the ZX8C combines durability with outstanding sound performance. Its slim 60mm mounting depth allows it to fit into a wide range of vehicles, making installation possible even where space is limited.
With an impressive 8mm of Xmax, the ZX8C provides deep excursion for clean, dynamic bass response while maintaining accuracy at higher volumes. Whether you’re upgrading your factory system or building a custom setup, the ZX8C is the perfect solution for anyone who demands powerful midbass in a compact design.
Key Features:
- Engineered for powerful midbass
- Slim basket design for versatile and easier fitment
- 1.5” high-performance copper voice coil
- Strong 28.3Oz Y35 magnet
- Rubber surround
- Polypropylene cone
- 8mm Xmax
Product Features:
- Speaker Type: Midbass
- Speaker Size: 8” (209mm)
- Frequency Response: 30Hz – 3000Hz
- Power Handling (RMS): 120W
- Power Handling (MAX): 240W
- Impedance: 4Ω
- Sensitivity: 87.7dB (1W/1m)
- Voice Coil: 1.5” (38mm)
- Displacement: 0.62 L
- Mounting Depth: 60 mm
- Mounting Diameter: 176 mm
- Outer Diameter: 209 mm
- Speaker Grills: No
- Unit: Sold as pairs
- Weight (Each Speaker): 2.0 kg
T/S PARAMETERS
- Re: 3.2 Ohm
- Fs: 45.49 Hz
- Qms: 3.552
- Qes: 0.412
- Qts: 0.369
- Cms: 294.1 μM/N
- Vas: 16.87 L
- BL: 9.612 Tm
- Sd: 201.1 cm²
- Mms: 41.62 g
- Le: 0.61 mH
- No: 0.374 %
- Xmax: 8 mm
- EBP: 110
Included in the package:
- 2 x ZX8C speakers
- 16 x Screws
- 16 x Metal Plate Clips
- 1 x Manual
