Focal ICU 690 Universal Integration Series 6" x 9" 2-way car speakers

The Focal ICU 690 is a universal 6x9-inch 2-way coaxial car speaker rated at 80W RMS, with a shallow 49mm mounting depth and integrated crossover. It is a direct upgrade for factory 6x9-inch door and rear deck locations.

Key specifications

• Size: 6x9" (164 x 235mm)
• Type: 2-way coaxial, integrated 6dB/oct crossover
• Power handling: 80W RMS (160W max)
• Sensitivity (2.83V/1m): 93.6 dB
• Frequency response: 55Hz - 21kHz
• Impedance: 4 ohms
• Mounting depth: 49mm (1.9")
• Cone: Polyglass with butyl surround
• Tweeter: aluminium/magnesium inverted dome, Flat/High (+3 dB) control

ICU 690: 2-way coaxial kit, 6x9" woofer

A direct upgrade for factory speakers, the ICU 690 fits standard 6x9 inch locations and delivers a clear step up in sound quality.

Natural sound

The ICU 690 uses a Polyglass diaphragm and an aluminium/magnesium inverted dome tweeter — both Focal innovations designed to produce clear, natural sound.

Easy installation

The 49mm mounting depth allows fitment in most door and rear deck locations. Protective grilles are included, with one designed specifically for rear panel use. The integrated crossover simplifies wiring.

Optimised treble

A two-position Flat/High level control adds +3 dB of treble boost — useful when the speaker is mounted low in a door, where high frequencies can lose presence.

• Configuration: 2-way coaxial
• Size: 6x9 inch
• Power handling: 80W RMS
• Mounting depth: 49mm
• Diaphragm: Polyglass
• Tweeter: aluminium/magnesium inverted dome
• Tweeter control: Flat/High (+3 dB)
• Includes: protective grilles, rear panel grille, integrated crossover

Product Features:

What's in the box:
